Standard finishing media

Ceramic Media

Ceramic media supports deburring, cutting, radiusing, and surface refinement.

8 product familiesCurrent details confirmed on quote
Five gray finishing media pieces in triangle, cylinder, and cone shapes arranged beside a US quarter
Shown with a US quarter for scale.
Browse the category

Pick the name or shape you know.

Add the full product when you need Kevin to confirm the size. Add an exact variant from the product page when you already know the code.

Composition reference

Composition changes the cut.

Use the composition codes listed on each ceramic shape as a comparison point. Kevin confirms the current match before quoting.

Code 61

Composition 61

An extremely hard, fine grained, abrasive-free ceramic media for light deburring, driving loose abrasives, and mild polishing. It may be compounded with loose grit abrasives for varied finishing requirements. It has exceptional impact resistance for its hardness. Media density is 85 lb/cu ft.

Code 62

Composition 62

A versatile, general-purpose, mildly abrasive media that combines a low wear rate with a respectable metal removal rate. The archived catalog identifies it as the media of choice for most high energy applications. Media density is 90 lb/cu ft. The abrasive is aluminum oxide.

Code 63

Composition 63

A high performance cutting, deburring, edge radiusing, and surface refinement media for fast metal removal and a fine finish with a moderate wear rate. It provides a faster, more aggressive cut than Composition 62. Media density is 95 lb/cu ft. The abrasive is aluminum oxide.

Code 64

Composition 64

An extremely fast cutting media for rapid cut down, radiusing, deburring, and surface refinement. It contains more fine fused aluminum oxide than Compositions 62 and 63. This gives a similar finish in less time with higher density and attrition. Media density is 100 lb/cu ft. The abrasive is aluminum oxide.

Code 65

Composition 65

A fast cutting and relatively fast wearing media for applications where exposure to aluminum oxide cannot be tolerated. The archived catalog lists cemented carbides, high alumina ceramics, and parts that will be welded or brazed later. Media density is 95 lb/cu ft. The abrasive is silicon carbide.

Code 69

Composition 69

The fastest cutting ceramic media listed in the archived catalog. It is used for rapid edge radiusing, surface refinement, and parting line removal. It is fracture and chip resistant and performs in high energy equipment. It is also the fastest wearing composition. Media density is 100 lb/cu ft.

Need the match checked?

Add the closest family. Send the old code.

Kevin can work from the product name, bag code, dimensions, photo, or a sample part. Current pricing and freight follow the match.

Review quote requestBack to all media
01

Know the exact code?

Open the product and add the variant row to your request.

02

Only know the shape?

Add the product family. Kevin confirms the dimensions with you.

03

Running another brand?

Include its label or a photo. The quote request has room for notes.
